Bauer Compressors Oceanus - Figure 1-3 Oceanus GS; Belt Side

MNL-0295
August 27, 2009 Page 5
Figure 1-3 Oceanus GS; Belt Side
1. Oil Dip Stick
2. Final Pressure Valve
3. P0 Purification System
4. Manual Condensate Drain Valve
5. Purification Bleed Valve
6. Subaru Gas Engine
7. Compressor Air Inlet
8. V-belt Guard
1
2
3
4
5
6
7
8
9
