Bauer Compressors Oceanus - Figure 3-16 Oceanus-G Gasoline Engine

Oceanus
Page 42 2nd Edition, Rev. 0 Chg. 14
Item Qty Part No. Description Notes
1 1 ENG-0082 Engine, Gasoline 6 Hp
1
, Subaru
2 1 SHE-0246 V-belt Sheave
3 1 BUS-0059 Sheave Bushing
4 1 BET-0046 V-belt
5 4 NUT-0119 Self Locking Hex Nut
6 4 N2460 Washer
7 4 WAS-0023 Washer”
8 4 N17082 Hex Head Cap Screw
9 2 SPC-0090 Spacer
10 2 WAS-0040 Washer
11 2 SCR-0329 Hex Head Bolt
Figure 3-16 Oceanus-G Gasoline Engine
1. Not available for Oceanus Yachting Package
1
2
3
4
5
6
7
8
9
10
11
9
10
11
