Bauer Compressors Oceanus - Replacement Parts List; Figure 5-9 P0 Purification System Parts List

Oceanus
Page 62 2nd Edition, Rev. 0 Chg. 14
5.2.4 Replacement Parts List
Item Qty Part No. Description Notes
♦ 1 077159-D-V001 P0 Purification System
1 † — Plug Available only with 077159-D-V001
2 2 N4586 O-ring
3 1 N25212 O-ring
4 † — Housing Available only with 077159-D-V001
5 † — Bottom Available only with 077159-D-V001
6 1 065500 Condensate Drain Tap Assembly
7 1 059183A Cartridge Assembly Includes Items 9 and 10
8 1 N4566 O-ring
9 1 N3824 O-ring
10 1 059410 Safety Valve
11 1 078538 Pressure Maintaining Valve
12 4 N19541 Socket Head Cap Screw
Figure 5-9 P0 Purification System Parts List
20
19
18
17
6
11
16
12
15
14
13
23
5
2
24
10
22
1
2
3
4
21
8
9
7
