Bauer Compressors Oceanus - Figure 1-6 Oceanus, V-Belt Pulley Side

MNL-0295
August 27, 2009 Page 7
Figure 1-6 Oceanus, V-belt Pulley Side
1. Fill Hose
2. Fill Valve w/Pressure Gauge
3. Final Pressure Safety Valve
4. P0 Filter System
5. Pressure Maintaining Valve
6. Fill Connector Yoke
7. Compressor Intake Filter
8. V-belt Shroud
9. Telescopic Intake Storage
(Gas Powered Units Only)
1
2
3
4
5
6
7
8
9
