Bauer Compressors Oceanus - Figure 3-4 Valve Function; Figure 3-5 1 St Stage Plate Valve

Oceanus
Page 20 2nd Edition, Rev. 0 Chg. 14
discharge valve open. The 1st Stage combines the intake and discharge valves in a common plate valve
assembly. (Figure 3-5)
Figure 3-4 Valve Function
Figure 3-5 1st Stage Plate Valve
Intake Discharge
S
Discharge
Side
Intake
Side
To
2nd
Stage
From
Intake
Filter
N4860-F98
