Bauer Compressors Oceanus - Figure 1-4 Oceanus with Three Phase Electric Motor; Figure 1-5 Oceanus with Single Phase Electric Motor

Oceanus
Page 6 2nd Edition, Rev. 0 Chg. 14
Figure 1-4 Oceanus with Three Phase Electric Motor
1. Fill Hose
2. Fill Valve w/Pressure Gauge
3. Motor Terminal Box
4. Three Phase Motor
5. Final Pressure Safety Valve
6. Handle
7. Fanwheel Shroud
8. Pressure Maintaining Valve
9. Condensate Drain Valve
Figure 1-5 Oceanus with Single Phase Electric Motor
1. Fill Hose
2. Fill Valve w/Pressure Gauge
3. Motor Terminal Box
4. Single Phase Motor
5. Final Pressure Safety Valve
6. Handle
7. Fanwheel Shroud
8. Pressure Maintaining Valve
9. Condensate Drain Valve
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
