5.1.4 Model, Serial Number and Part Number Identification
5.1.4.1 Compressor Dataplate
The model number, date of manufacture and serial number can be found on the compressor unit identifi-
cation plate in the main electrical enclosure and frame.
5.1.4.2 Purification System Dataplate
Refer to the compressor unit purification system dataplate (See Figure 5-2) on the compressor front to
determine your purification system model and specifications
5.1.4.3 Cartridge Installation Dataplate
The function performed by each chamber in the purification system is determined by the type of cartridge
installed in that chamber. Refer to the cartridge installation dataplate on the chamber to determine the
purpose and part number of the cartridge installed in that chamber. (See Figure 5-2).
Figure 5-2 Purification Dataplates (typical)
Purification System Dataplate Cartridge Installation Dataplate
CARTRIDGE FOR
CARTRIDGE NO.
LBL-
CARTRIDGE TO BE
INSTALLED
1328 Azalea Garden Road - Norfolk Virginia 23502-1944
Phone: (757) 855-6006 Fax: (757) 855-8224
MODEL NO.
MAX. PRESSURE
AIR PROCESSED
O-RING
BACK-UP RING
psig
cu. ft.
LBL-
PURIFICATION
SYSTEM
