Oceanus
Page 60 2nd Edition, Rev. 0 Chg. 14
6. Tighten the indicator cap (2) hand tight.
Figure 5-8 Moisture Indicator
1. Indicator Cap
2. Indicator Element
3. Spring
4. Indicator Base
1
2
3
4
5
