Bauer Compressors Oceanus - Electric Drive Replacement Parts; Figure 6-6 Oceanus, Drive Assembly

MNL-0295
August 27, 2009 Page 69
6.6 Electric Drive Replacement Parts
Item Qty Part No. Description Notes
♦ Oceanus-E1
1 1 Air Compressor
2 1 BET-0172 V-belt
3 1 SHE-0299 V-belt Sheave
N.S. 1 MTR-0221 Electric Motor 5 Hp
Item Qty Part No. Description Notes
♦ Oceanus E3
1 1 Air Compressor
2 1 BET-0140 V-belt
3 1 SHE-0299 V-belt Sheave
N.S. 1 MTR-222 Electric Motor 5 Hp
Item Qty Part No. Description Notes
♦ Oceanus-G G
1 1 Air Compressor
2 1 BET-0140 V-belt
3 1 SHE-0298 V-belt Sheave
N.S. 1 ENG-0082 Engine, Gasoline 6.0 Hp, Subaru
— 1 ENG-0024 Engine, Gasoline 5.5 Hp, Honda
Figure 6-6 Oceanus, Drive Assembly
1
2
3
4
