MNL-0295
August 27, 2009 Page 41
Figure 3-15 (cont.) Frame with Accessories
Item Qty Part No. Description Notes
16 2 N26621 Washer
17 1 85145 V-Belt Shroud Cyan
— 1 80457 V-Belt Shroud Turquoise
18 2 N15627 Grommet
19 4 N26506 Washer
20 8 N24918 Button Head Allen Screw
21 1 81104 Bracket
22 2 N102 Washer
23 1 N16131 Rubber Isolator
24 1 77674 Fill Hose Holder
25 1 80455 Bracket Electric Motor Driven Units Only
