MNL-0295
August 27, 2009 Page 31
Figure 3-10 (cont.) Crankcase, Driving Gear and Fanwheel
Item Qty Part No. Description Notes
16 1 78346 Gasket
17 1 N25507 Oil Pump
18 6 N25542 Hex Head Screw
19 1 13920 Fan
20 1 N2460 Washer
21 1 N19547 Allen Screw
22 1 N108 Split Lock Washer
23 2 N19533 Allen Screw
24 2 N3026 Wave Washer
25 1 78445 Dip-stick
26 1 N3951 O-ring
27 1 67007 Oil Filler
28 1 N1055 Hose
29 1 12560 Paper Gasket
