Parameter
Parameter manual b maXX
®
1000
Document no. 5.07004.03
143
of 208
4
P2072
Display the signal of AO2 analog output [mA or V].
4095 Inc
⇔ 20.0 mA or 10.0 V
0 - 4095 Inc
⇔ 0.0 - 20.0 mA or 0.0 - 10.0 V
P2073
Display the speed actual value in rpm.
P2080
The coefficient K determines the multiplying factor for the user-defined unit.
The display value is calculated as follows:
U (User-defined unit) = Actual output frequency * K ZP2080–
Example:
A conveyor belt runs at 13.6 m/s at motor speed 60 Hz.
K = 13.6/60 = 0.22 (0.226667 rounded to 1 decimal), therefore ZP2080– = 0.2
With Frequency command 35 Hz, display shows U and 35
⋅ 0.2 = 7.0 m/s.
(To increase accuracy, use K = 2.2 or K = 22.7 and disregard decimal point)
P2081
ZP2081– and ZP2082– are used to record the motor operation time. They can be
cleared by setting to 0 and time is less than 1 minute is not recorded.
P2072
Anzeige AO2 analoger Ausgang 0 to 65535
- Display of AO2 analog output 0
A BM_u_AO2AnalogOutput 1:1 -
P2073
Anzeige Geschwindigkeits-Istwert in U/min 0 to 36000 rpm
- Display speed actual value in rpm 0 rpm
A BM_u_DisplaySpeedActValue 1:1 -
P2080
Benutzerdefinierter Faktor K 0.1 to 160.0
EE User defined coefficient K 1.0
ON BM_u_UserDefinedCoeffK 10:1
P2081
Motorbetriebszeit (Minuten) 0 to 1439
- Accumulative motor operation time (min) 0
A BM_u_AccumulMotorOperationTimeMin 1:1
