Baumuller b maXX 5000 Application Handbook

Parameters
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02
61
of 76
6
177.2 Status word 
DWORD 0x00000000 to 0xFFFFFFFF
Status word of servo pump.
177.3 Controlword 1 
DS-support WORD 0x0000 to 0xFFFF
Control word 1 of servo pump.
Bit Meaning
0 … 12 Reserved
13 Pump protection:
0: disabled 1: active
14 … 15 Reserved
Bit Meaning
0 Adaption of pressure controller parameter
0: disabled 1: active
1 … 4 Reserved
5 Interpolation of adaption parameter
0: disabled 1: active
6 Speed set value 0 in case of pressure limits are fallen below
0: disabled 1: active
7 Switching pressure sensor
0: sensor 2 (input 2 standard X6 / input 4 add-on module SVP)
1: sensor 1 (input 1 standard X6 / Input 3 add-on module SVP)
8 … 9 Interface set and actual values
00: Reserved
01: Set values via field bus, pressure actual value via add-on module SVP
10: Set values via field bus, pressure actual value via standard X6
11: Set values and pressure actual value via add-on module SVP
10 … 13 Reserved
14 Display pressure
0: Volt
1: Bar
15 Display Volume
0: rpm
1: liters / min
