Baumuller b maXX 5000 Application Handbook

Parameter description
Application handbook Servo pump function V1 for BM5000
Document No.: 5.17002.02 Baumüller Nürnberg GmbH
62
of 76
6.3
177.4 Controlword 2 
DS-support WORD 0x0000 to 0xFFFF
Control word 2 of servo pump.
177.6 Bar value 
DS-support DINT 1 to 100000
Maximum pressure value of pressure sensor.
Scaling: 100000 Inc = 1000 Bar
177.7 Volt value 
DS-support DINT 1 to 10000
Maximum voltage/current output of pressure sensor.
Scaling: 10000 Inc = 10 V / 20 mA
177.8 Flow rate 
DS-support DINT 1 to 100000
Maximum voltage/current output of pressure sensor.
Scaling: 10000 Inc = 1000 cm³/rev
177.20 P set value bus 
DINT 1 to 2147483.647
Pressure set value for field bus interface.
Scaling: 1 Inc = 1 mBar
Bit Meaning
1 … 3 Reserved
4 Pump protection
0: disabled 1: active
5 … 11 Reserved
12 Negative volume set values
0: prohibited 1: allowed
13 … 15 Reserved
