Baumuller b maXX BM4 Series Instruction

Design and Operation
Instruction Handbook b maXX (BM4-F-)ENC-XX (Encoder module)
Document No.: 5.01042.12
29
of 102
4
Here is a choice of encoder that can be connect to (BM4-F-)ENC-XX:
Type For encoder Encoder type Connectable encoders
examples
ENC-01
BM4-F-ENC-01
Resolver Resolver,
transmission ratio: 0,5
ENC-11
BM4-F-ENC-11
Resolver reduced level Resolver,
transmission ratio: 0,28
ENC-21
BM4-F-ENC-21
Resolver
replaces BM4-F-ENC-01
Resolver,
transmission ratio: 0,5
ENC-02
BM4-F-ENC-02
Sine cosine encoder with Hip-
erface
®
interface
Sine cosine encoder single-turn Stegmann
SCS60/70
Stegmann
SRS50/60
Sine cosine encoder multi-turn Stegmann
SCM50/60
Stegmann
SRM50/60
ENC-12
BM4-F-ENC-12
Sine cosine encoder with
Hiperface
®
interface without
termination in communication
Sine cosine encoder single-turn Stegmann
SCS60/70
Stegmann
SRS50/60
Sine cosine encoder multi-turn Stegmann
SCM50/60
Stegmann
SRM50/60
ENC-03
BM4-F-ENC-03
5V square wave incremental
encoder
5V square wave incremental encoder,
RS422 output signals (TTL)
Heidenhain
ROD 426
SickStegmann
DRS60
ENC-04
BM4-F-ENC-04
Sine cosine incremental
encoder with zero-point sens-
ing
5V sine cosine encoder,
output signals ~1Vss
Heidenhain
ROD 486
Hengstler RIS
58
ENC-05
BM4-F-ENC-05
Sine cosine encoder with
EnDat
®
2.1 interface
Sine cosine encoder single-turn
Sine cosine encoder multi-turn
Length measurement systems
Heidenhain
ECN 413
EQN 425
LC 481
Heidenhain
ECN 113
EQN 1325
LC 181
ENC-06
BM4-F-ENC-06
Encoder with EnDat
®
2.2 inter-
face
Encoder for absolute position sensing
with EnDat
®
2.2 interface
Heidenhain
ECN 1325
single-turn
Heidenhain
EQN 1337
multi-turn
ENC-07
BM4-F-ENC-07
Sine cosine encoder with SSI
interface
Sine cosine encoder, output signals
~1 Vss, external encoder supply
SIKO
AEA111
ENC-17
BM4-F-ENC-17
Sine cosine encoder with SSI
interface and 5 V encoder sup
-
ply
5V sine cosine encoder,
output signals ~1 Vss
Baumer-
Hübner
MHGA400
ENC-27
BM4-F-ENC-27
Encoder with SSI interface and
24
V encoder supply
SSI encoder with digital output sig-
nals and 24 V encoder supply
MTS-Sensors
Temposonics
ENC-08
BM4-F-ENC-08
Sine cosine incremental
encoder with commutation and
zero-point sensing
5V sine cosine encoder,
incremental signals ~1Vss,
commutation signals ~1 Vss
Heidenhain
ERN1185
Heidenhain
ERN1387
