Baumuller b maXX BM4 Series Instruction Handbook

Error handling
Instruction handbook b maXX (BM4-F-)AIO-XX (Analog IO module)
Document No.: 5.01045.08 Baumüller Nürnberg GmbH
70
of 82
10.3
1st level 1st level errors are only interesting for the access to errors via parameters, to be used
without ProDrive, e. g. at Field bus communication. These errors are not shown in Pro
-
Drive/7-segment display.
Bit mapping see description of the parameter P0200 in the parameter manual.
2nd level
3rd level
Order of the error messages see survey (ZAbbildung 28– auf Seite 69).
2nd level error messages are displayed on the 7-segment display in ProDrive.
In the column „Reaction“ the reaction of the system to the error is shown:
m „pulse stop“ = inhibit pulses
m „adjustable“ = the error reaction can be set via ProDrive (Window „Drive management“,
toolbar button „Error reaction“).
m „no reaction“ means, the drive is continuing to work and the red error LED is blinking.
2nd level
error messages
P0204 Error in function or option modules
Error No. Meaning Reaction Troubleshooting
48 Error in function module A 3rd level
error
see
ZError in function module A to E– on page 71 (= 3rd
level)
49 Error in function module B
50 Error in function module C
51 Error in function module D
52 Error in function module E
