The following settings are possible for each of the 6 time intervals:
Sub-menu Programable timer (1..6)
Days of week Selection of one or multiple weekdays on which the
time interval should be active.
If no weekday is activated, then the entire time
interval is inactive.
Switch-on time Time at which switch-on occurs.
Switch-off time Time at which switch-off occurs
Interval mode Activation of interval operation
(Periodic switching on and off)
Switch-on interval Switch-on duration for interval operation.
Switch-off interval Switch-off duration for interval operation.
24.3.2 Basic configuration
The menu Basic configuration is used to configure the basic settings
for a switch output. This is generally done once upon placing a switch
output into operation.
The following settings are available:
Sub-menu Basic configuration
Relay output Relay switch output used for the universal switch
output.
Block in the event of
missing flow
Yes Output is turned off if flow signal is missing.
Blocking by filter
pump operating mode
Yes The output is turned off if the filter pump is in
the corresponding operating mode.
Prerequisite: PoolManager
®
controls the filter pump.
Blocking via input. Yes The output is turned off if the selected input is
in the state indicated.
Blocking by another
output
Yes The output is turned off if the other output
selected is in the state indicated.
External switch or
push buttons
See External switch or push button.
For each relay switch output, the following settings are available:
Setting Description
None The universal witch output is not used.
OUT 1 [26] Relay switch output OUT 1 [terminal block 26]
OUT 2 [27] Relay switch output OUT 2 [terminal block 27]
OUT 3 [30] Relay switch output OUT 3 [terminal block 30]
OUT 4 [31] Relay switch output OUT 4 [terminal block 31]
pH+ [22] Dosage relay pH + [terminal block 22]
Can only be used
if no pH+ dosage is used.
pH- [21] Dosage relay pH + [terminal block 21]
Can only be used
if no pH- dosage is used.
INFO
Terminal block indication
For
the relay outputs OUT1 ... OUT4, the terminal block
number is indicated directly in the menu. This is the
number in brackets, e.g. [26] for OUT1.
INFO
Toggle switch OUT4
The relay output OUT4 is designed as a toggle switch.
When active (on), terminal
When inactive (off), terminal block [32] is turned on.
All other switch outputs are designed as simple on/off
switches.
24.3.2.1 External switch or push buttons
Each switch output can be linked with an external switch or device,
which facilitates turning the function on or off manually.
The following settings can be configured:
Sub-menu External switch or device
External switch input Selection of an input to which the external switch is
connected
(IN 1 [6] / IN 2 [7] / IN 3 [8] / IN 4 [9] / none)
Type of external
switch
On/off switch or push button.
For on/off switch only
External switch Defines the operating mode when external
switch is turned on:
• Output ON
• Output AUTO,
(Operating mode controlled by PoolManager
®
)
External switch off Defines the operating mode when external
switch is turned off:
• Output OFF
• Output AUTO,
(Operating mode controlled by PoolManager
®
)
For push buttons only
Function of external
push buttons
Start timer or
Output on/off
Timer for
external push button
Switch-on duration
(For the function Start timer)
24.3.3 Security settings
HAZARD!
Hazard via remote access
Depending on the installation, hazards may be yielded
by universal switch outputs, particularly via
access.
Potential consequence: Death or the gravest
degree of injury, heavy material damage.
•
Release of remote access to universal switch
outputs is expressly PROHIBITED for all
applications in which the safety of persons,
animals, and property is n
at all times and under all circumstances; especially
for remote access.
•
Safety is exclusively in the system operator's
sphere of responsibility.
• The device manufacturer disclaims all liability.
