Page15

Figure 1: Outlet Status

MMP-11 Series

F2.01

Option(s) Installed:

True RMS Current

Internal Temperature

Total kW-h: 3221351

Phase Currents A: 0.0A B: 0.0A C: 0.0A

------------------------------------------

| Circuit | True RMS | Peak RMS |

| Breaker | Current | Current |

------------------------------------------

| CKT1 | 0.0 Amps | 2.3 Amps |

| CKT2 | 0.0 Amps | 0.0 Amps |

| CKT3 | 0.0 Amps | 0.1 Amps |

-------------------------------------------------------------------------------

-------------------------------------------------------------------------------

-------------------------------------------------------------------------------

Int. Temp: 122.0 F

Switch 1: Open 2: Open

1)...MOD 1 Outlet 1 : On 2)...MOD 1 Outlet 2 : On

3)...MOD 1 Outlet 3 : On 4)...MOD 1 Outlet 4 : On

5)...MOD 2 Outlet 1 : On 6)...MOD 2 Outlet 2 : On

7)...MOD 2 Outlet 3 : On 8)...MOD 2 Outlet 4 : On

9)...MOD 3 Outlet 1 : On 10)...MOD 3 Outlet 2 : On

11)...MOD 3 Outlet 3 : On 12)...MOD 3 Outlet 4 : On

13)...MOD 4 Outlet 1 : On 14)...MOD 4 Outlet 2 : On

15)...MOD 4 Outlet 3 : On 16)...MOD 4 Outlet 4 : On

17)...MOD 5 Outlet 1 : On 18)...MOD 5 Outlet 2 : On

19)...MOD 5 Outlet 3 : On 20)...MOD 5 Outlet 4 : On

21)...MOD 6 Outlet 1 : On 22)...MOD 6 Outlet 2 : On

23)...MOD 6 Outlet 3 : On 24)...MOD 6 Outlet 4 : On

Type Help for a list of commands

MMP-11>

Status Screen: Once the serial connection is made using the terminal software, the screen will display

the inherent state of the outlets, the Average Power, RMS voltage, Current and Maximum Detected

Current both in Amps, circuit breaker, Internal temperature of the unit, and external temperature

sensors if connected. The number of outlets displayed depends on the MMP model.

BayTech MMP User Manual
