Page44
NetworkPortConfiguration
Menu 7: Network Port Configuration
IPv4Configuration
IPAddress
The IP address is the network address assigned by your network manager for your network. The IP
Address consists of four bytes, each byte ranging from 0 to 255. This parameter must be programmed
before the MMP can be accessible via the network.
NOTE: There should be no active connections while configuring the MMP. The unit should be
reset upon completion of configuration.
Select 8), from the Network Configuration
Menu, this menu is used to change the
network configuration options such as the IP
Address, Subnet Mask, Gateway, DHCP,
and Telnet; all of which are necessary during
initial startup. The Connection Inactivity
Timeout allows you to enable/disable
whether the firmware will end your session
or “times out.” The default is 1 hour, but
when disabled there is no set time out.
Disabling the Carriage Return Translation
allows you to bypass all unnecessary
carriage returns, and it will send you straight
to the next “end of line.” The DHCP,
Telnet, SSH, options is to enable or disable
these functions. SSH host key Generator
allows the user to generate a host key which
is used in the SSH encryption process. IP
Filter allows or blocks specific IP
Addresses, SNMP provides a message format for communication between a computer and your devices,
and Web Server Configuration allows web access and sets up options for each.
Network setup :
Ethernet Address................ 00:C0:48:00:01:FD
IP Address...................... 70.150.140.89
Subnet Mask..................... 255.255.255.224
Default Gateway................. 70.150.140.65
Connection Inactivity Timeout (mins): Disabled
Carriage Return Translation: Enabled
Break Length (msecs): 350
DHCP is Disabled Telnet is Enabled SSH is Enabled
SSH host keys are set to factory default
IPv4 Configuration................1
IPv6 Configuration................2
Inactivity Timeout................3
Carriage Return Translation.......4
Break Length......................5
DHCP Enable/Disable...............6
Telnet Enable/Disable.............7
SSH Enable/Disable................8
SSH Host Key Generation...........9
IP Filter Configuration...........10
SNMP Configuration................11
Web Server Configuration..........12
Exit..............................X,CR
Enter Request :
IMPORTANT: For network access, you must configure the IPv4: IP addresses, Subnet Mask,
and Gateway or IPv6: IP Address, Network Prefix Size and Gateway. A unit reset must be
performed for network changes to take effect.
Select 1), to enter the IP Address. Failure to enter the address in the decimal form causes the unit to
display the following until it is entered correctly.
Default Module IP Address is 0.0.0.0.
Enter IP address in dotted decimal form :
This option is for setting the IP Version-4. The menu options
are IP Address, Subnet, and Gateway.
P Address........................1
Subnet Mask.......................2
Gateway...........................3
Enter Request :
NOTE: IPv6 is only available for network firmware version F4.00.00 or higher
