Page30
ChangeDisplayOrientation
DisplayCurrentElectricalCharacteristics:
Type “current” at the prompt to show the unit’s True
RMS Current and Peak RMS Current, and the unit will
display the following:
------------------------------------------
| Circuit | True RMS | Peak RMS |
| Group | Current | Current |
------------------------------------------
| Circuit C1 | 0.0 Amps | 0.7 Amps |
| Circuit C2 | 0.0 Amps | 0.0 Amps |
| Circuit C3 | 0.1 Amps | 0.5 Amps |
| Circuit C4 | 0.0 Amps | 0.9 Amps |
| Circuit C5 | 1.2 Amps | 1.8 Amps |
| Circuit C6 | 0.9 Amps | 1.4 Amps |
------------------------------------------
Type “Voltage” at the prompt to display the unit’s True RMS
Voltage, and the unit will display the following:
Select 7) from the Outlet Control Menu, flips the data displayed in the
LCD/LED screen on the unit controller.
The unit will display either of the following:
Flip Display (Y/N)? y
Or
Normal Display (Y/N)? y
Type “N” to keep the current value or type “Y” to
change the value and enter the new value, press
“Enter’ and the unit will display next circuit group.
Circuit breaker 1 buzzer alarm value : 12.0 Amps
Modify (Y/N)? y
Enter: 15
Circuit breaker 2 buzzer alarm value : 12.0 Amps
Modify (Y/N)? y
Default setting is 12.0 Amps.
Select 1), CircuitBreakerAlarm
, changes the
alarm level per circuit breaker.
Circuit M1 buzzer alarm value : 12.0 Amps
Modify (Y/N)? y
Enter: 10
Select 2), Module/GroupCircuitBreaker
Alarms, changes the alarm level per module.
Circuit M2 buzzer alarm value : 12.0 Amps
Modify (Y/N)? y
Enter: 10
Type “clear” at the prompt to reset the Peak RMS Current, the unit will redisplay the status menu with
the new maximum detected current.
--------------------------------
| Circuit | True RMS |
| Group | Voltage |
--------------------------------
| Circuit C1 | 201.9 Volts |
| Circuit C2 | 204.3 Volts |
| Circuit C3 | 202.4 Volts |
| Circuit C4 | 202.1 Volts |
| Circuit C5 | 204.5 Volts |
| Circuit C6 | 205.8 Volts |
