BayTech MMP User Manual

Page38
SerialPortDeviceName
AttentionCharacter
DisconnectTimeguard
ConnectPortIDEcho
P
ort ID Echo is...................Disable
d
Connect Port ID Echo Menu
Disable Port ID Echo..............1
Use Module, Port Number...........2
Use Device Name...................3
Exit..............................X,CR
Enter Request :
Select 1), to disable the echo. The Default setting is Disabled.
The unit displays: (blank)
Select 2), to echo the module and port number.
Select 3), to echo the device name.
The unit displays:
BAYTECH
For further information check:
http://www.baytech.net/
02,1
The unit displays:
BAYTECH
For further information check:
http://www.baytech.net/
MMP10
Current device name: EIA-RS232
Enter device name for serial port ((1 - 16 char., CR to end) :
Pressing the Attention Character 5 consecutive times will access the
network main menu. Select 4), from the Network Configuration
Menu, sets the attention character. The unit displays the following: The
Default is a semi-colon (;).
Attention Character is........... ;
Enter Attention Character :
Select 5), from the Network Configuration Menu, ensures reliable binary data transmission by
providing a one-second “Timeguard” after the unit receives the attention character. If more data is
received within the delay period, the unit treats the character as data, not an attention character; thereby
preventing unwanted port disconnection. Select 5, from the
network menu. The Default setting is Disabled.
Disconnect Time Guard is.......... Disabled
Enable ? (Y/N), CR for no change) :
Select 3), from the Network
Configuration Menu allows the serial
port to be renamed. Type the new port
name and press ‘Enter’.
Select 6), from the Network Configuration
Menu, sets the port identification. The unit
displays the Port ID Echo Menu.
