BayTech MMP User Manual

Page16
Help Menu: Type Help followed by a <CR> to view the line commands for the MMP outlet control.
Figure 2: Outlet HELP
Figure 3: Outlet Password Set
Figure 4: Outlet Configuration
MMP-11>help
On n <cr> --Turn on an Outlet, n=0,1...36,all
Off n <cr> --Turn off an Outlet, n=0,1...36,all
Reboot n <cr> --Reboot an Outlet, n=0,1...36,all
Status <cr> --MMP-10 Status
Ostatus <cr> --MMP-20 Meter Outlet Status
Config <cr> --Enter configuration mode
Lock n <cr> --Locks Outlet(s) state, n=0,1...36,all
Unlock n <cr> --Unlock Outlet(s) state, n=0,1...36,all
Current <cr> --Display True RMS Current
Voltage <cr> --Display True RMS Voltage
Power <cr> --Display Average Power
Clear <cr> --Reset the maximum detected current
Temp <cr> --Read current temperature
Logout <cr> --Logoff
Logoff <cr> --Logoff
Exit <cr> --Logoff
Password <cr> --Changes the current user password
Whoami <cr> --Displays the current user name
Unitid <cr> --Displays the unit ID
Type Help for a list of commands
MMP-11>
MMP>password
Enter new Password: *****
Re-Enter new Password: *****
Type Help for a list of commands
MMP>
MMP>config
Unit ID: MMP11
1)...Manage Users Add/Delete/Rename, assign outlets
2)...Change Outlet Name Select an outlet to change its name
3)...Enable/Disable Confirmation Confirmation (Y/N)
4)...Enable/Disable Status Menu Opening status of outlets
5)...Change Unit ID As written
6)...Change Alarm Threshold As written
7)...Change Display Orientation Flip Display
X)...Exit
NOTE: If the unit display with the following message, “Configuration mode in use”
A user in the other port is in the “Configuration” menu.
Power Controller Configuration Menu: To select the configuration menu, type “config” at
the prompt.
Password setting: Once you have logged out and log back in as a user or as the
administrator, you can then set the password to gain access. Type “Password”<cr>
