Page22
OUTLETCONTROLLERSTATUSSCREEN
MMP-11 Series
(C) 2008 BayTech
F2.01
Option(s) Installed:
True RMS Current
Internal Temperature
Total kW-h: 3221351
Phase Currents A: 0.0A B: 0.0A C: 0.0A
------------------------------------------
| Circuit | True RMS | Peak RMS |
| Breaker | Current | Current |
------------------------------------------
| CKT1 | 0.0 Amps | 2.3 Amps |
| CKT2 | 0.0 Amps | 0.0 Amps |
| CKT3 | 0.0 Amps | 0.1 Amps |
-------------------------------------------------------------------------------
| Circuit | True RMS | Peak RMS | True RMS | Average | Volt- |
| Group | Current | Current | Voltage | Power | Amps |
-------------------------------------------------------------------------------
| Circuit M1 | 0.0 Amps | 2.2 Amps | 209.0 Volts | 0 Watts | 0 VA |
| Circuit M2 | 0.0 Amps | 0.0 Amps | 209.6 Volts | 0 Watts | 0 VA |
| Circuit M3 | 0.0 Amps | 5.9 Amps | 208.8 Volts | 0 Watts | 0 VA |
| Circuit M4 | 0.0 Amps | 0.0 Amps | 208.7 Volts | 0 Watts | 0 VA |
| Circuit M5 | 0.0 Amps | 0.1 Amps | 208.6 Volts | 0 Watts | 0 VA |
| Circuit M6 | 0.0 Amps | 0.0 Amps | 208.9 Volts | 0 Watts | 0 VA |
-------------------------------------------------------------------------------
Int. Temp: 122.0 F
Switch 1: Open 2: Open
1)...MOD 1 Outlet 1 : On 2)...MOD 1 Outlet 2 : On
3)...MOD 1 Outlet 3 : On 4)...MOD 1 Outlet 4 : On
5)...MOD 2 Outlet 1 : On 6)...MOD 2 Outlet 2 : On
7)...MOD 2 Outlet 3 : On 8)...MOD 2 Outlet 4 : On
9)...MOD 3 Outlet 1 : On 10)...MOD 3 Outlet 2 : On
11)...MOD 3 Outlet 3 : On 12)...MOD 3 Outlet 4 : On
13)...MOD 4 Outlet 1 : On 14)...MOD 4 Outlet 2 : On
15)...MOD 4 Outlet 3 : On 16)...MOD 4 Outlet 4 : On
17)...MOD 5 Outlet 1 : On 18)...MOD 5 Outlet 2 : On
19)...MOD 5 Outlet 3 : On 20)...MOD 5 Outlet 4 : On
21)...MOD 6 Outlet 1 : On 22)...MOD 6 Outlet 2 : On
23)...MOD 6 Outlet 3 : On 24)...MOD 6 Outlet 4 : On
Type Help for a list of commands
MMP-11>
NOTE: Int. Temp = unit internal temperature. Ext = external temperature probe. Two
environmental ports are available. Temperature reads in Fahrenheit or Celsius.
RH = Relative humidity.
NOTE: The user will see only those outlets assigned to them by the ADMIN user.
With NO assigned user, any log in is treated as the ADMIN User.
Type “Help” at the prompt to display a list of commands to change the outlet state,
outlet configuration, and internal sensor measurements.
The Outlet Controller displays the measured circuit True RMS and Peak RMS current values; True RMS
Voltage; Average Power, Voltage/Amps; Internal and External temperature and Humidity with attached
probes; along with Open/Close external Switch probes. Also displays the outlet status. At the prompt type
“Help” for outlet command and other menus
.
NOTE: a 30 minute timer starts when first connected to the Outlet ‘RC’ screen. If you need to work
in the Outlet ‘RC’ and the sub-screens for longer than 30 minutes, before the 30 minutes timeout, go
to the Network menu for 30 seconds then select option-1 from the network menu to return to the
Outlet ‘RC’ screen. THIS IS CANNOT BE CHANGED.
