BayTech MMP User Manual

Page34
NETWORKCONFIGURATIONMENU:
Menu 1: Network Configuration
Status
Copyright(C) Bay Technical Associates 2009
URPC Ethernet Host Module
Revision F 2.25.06 Module 1
Hardware 1.01 Serial number 25920003 colilo version 1.05.01
Status..........................1 Status of all network options
Serial Port Configuration.......2 Setup the Serial port EIA232
Serial Port Device Name.........3 Change the EIA232 port name
Attention Character.............4 Type 5 times to access Network Main menu.
Disconnect Timeguard............5 Data received within the delay period,
is data, not attention character; thereby
preventing unwanted port disconnection
Connect Port ID Echo............6 Echo port name or module# & port#
Login Setup.....................7 Login Menu Serial/Telnet/Radius/TACACS
access control, manage users
Network Port Configuration......8 Network Port IP Address
Module Name.....................9 Change name of module
Power Device Management........10 Set up Voltage/Current/Sensor threshold
Firemware / Config Download....11 Upload FTP firmware, upload and download
unit configuration
Exit.........................X,CR
Enter Request :
NOTE: The following message, “Configuration mode in use”, signifies a user in the other port is
in the “Configuration” menu.
I
nstalled Modules :01
Attention Character is ......... ;
Disconnect Time Guard is........ Disabled
Port ID Echo is................. Disabled
Module Name is.................. Universal RPC
Network Connectivity & Login Configuration:
Ethernet Address................ 00:C0:48:35:DD:40
IP Address...................... 192.168.2.214
Subnet Mask..................... 255.255.255.0
Default Gateway................. 192.168.2.1
Inactivity Timeout (mins)....... Disabled
Break Length (msecs)............ 350
Telnet.......................... Enabled
SSH............................. Enabled
DHCP............................ Disabled
Telnet login prompt is.......... Enabled
Serial login prompt is.......... Disabled
Cascade Mode is................. Disabled
SNMP & Web Configuration:
SNMP Agent is................... Enabled
SNMPv3 only i................... Disabled
SNMP Read-Only Community........ public
SNMP Read-Write Community....... private
Web Server is................... Enabled
Web Login is.................... Enabled
Web Secure Connection is........ Disabled
Select 1), displays the current
configuration of the unit network
information.
