BayTech MMP User Manual

Page21
DetailOperationsandConfigurations
NETWORKMENU
Single Unit Menu
CASCADE ENABLED Menu
The Network menu can be accessed through the Ethernet or
Console (serial) port..
(1), opens the Outlet Controller Menu, Ethernet unit.
(2), opens the Outlet Controller Menu, Non-Ethernet unit.
(O), opens the Cascade Outlet Controller Menu.
(S), opens the Ethernet data Status.
(C), opens the Network Configuration Menu.
(RU), opens the reset decision.
(T), close session
NOTE: Option (2) and option (O) are for units set for
Cascade operations.
Module: 1
Attention Character: ;
MMP11 (2 ,1).........1
Status..........................S
Configure.......................C
Unit Reset......................RU
Logout..........................T
Enter Request :
U
niversal RPC login: root
Password:
BAYTECH
For further information check:
http://www.baytech.net/
opening access to internal RPC
MMP-11 Series
(C) 2008 BayTech
F2.01
Option(s) Installed:
True RMS Voltage
True RMS Current
Internal Temperature
After logging into the unit, the unit will display
additional hardware information:
Outlet controller firmware, F1.11
Options installed Voltage and Current sensors and
Internal Temperature Sensor.
(Opening access to internal RPC) signifies the
processor is checking to see what is installed.
“Enter user name:” will appear if a user has been
assigned to the Outlet Controller.
Module: 1
Attention Character: ;
MMP11 Pri (2 ,1).........1
MMP11 Sec (2 ,2).........2
Outlet Group Control............O
Status..........................S
Configure.......................C
Unit Reset......................RU
Logout..........................T
Enter Request :
