Page24
STATUS
Ostatus
This shows the current status
of all circuit to the circuit
breaker level. It shows Circuit
Groups, True RMS Current,
Peak RMS Current, True RMS
Voltage, Average Power, and
Volt-Amps. Status also shows
whether the outlets are on, off,
or locked. NOTE: Each
module draws about 4VA with
nothing plugged in to the
module outlets, due to the
sensors on the module.
MMP-14>Ostatus
-------------------------------------------------------------------------------
| Outlet |True RMS|Peak RMS|True RMS |Average | Volt- | Outlet |
| Name | Current| Current| Voltage | Power | Amps | State |
-------------------------------------------------------------------------------
| CKT 1 Outlet 1 | 0.0 A | 0.2 A | 116.7 V | 0 W | 4 VA | On |
| CKT 1 Outlet 2 | 0.0 A | 0.2 A | 116.7 V | 0 W | 4 VA | On |
| CKT 1 Outlet 3 | 0.0 A | 0.0 A | 116.7 V | 0 W | 4 VA | On |
| CKT 1 Outlet 4 | 0.0 A | 0.1 A | 116.7 V | 0 W | 4 VA | On |
| CKT 1 Outlet 5 | 0.0 A | 0.1 A | 116.7 V | 0 W | 4 VA | On |
| CKT 2 Outlet 1 | 0.1 A | 0.1 A | 117.8 V | 0 W | 19 VA | On |
| CKT 2 Outlet 2 | 0.0 A | 0.1 A | 117.8 V | 0 W | 4 VA | On |
| CKT 2 Outlet 3 | 0.1 A | 0.1 A | 117.8 V | 0 W | 19 VA | On |
| CKT 2 Outlet 4 | 0.1 A | 0.1 A | 117.8 V | 0 W | 19 VA | On |
| CKT 2 Outlet 5 | 0.0 A | 0.1 A | 117.8 V | 0 W | 4 VA | On |
| CKT 3 Outlet 1 | 0.0 A | 0.2 A | 116.1 V | 0 W | 4 VA | On |
| CKT 3 Outlet 2 | 0.0 A | 0.2 A | 116.1 V | 0 W | 4 VA | On |
| CKT 3 Outlet 3 | 0.0 A | 0.2 A | 116.1 V | 0 W | 4 VA | On |
| CKT 3 Outlet 4 | 0.0 A | 0.2 A | 116.1 V | 0 W | 4 VA | On |
| CKT 3 Outlet 5 | 0.0 A | 0.2 A | 116.1 V | 0 W | 4 VA | On |
| CKT 4 Outlet 1 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 4 Outlet 2 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 4 Outlet 3 | 0.1 A | 0.2 A | 118.0 V | 0 W | 19 VA | On |
| CKT 4 Outlet 4 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 4 Outlet 5 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 5 Outlet 1 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 5 Outlet 2 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 5 Outlet 3 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 5 Outlet 4 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 5 Outlet 5 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 6 Outlet 1 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 6 Outlet 2 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 6 Outlet 3 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 6 Outlet 4 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
| CKT 6 Outlet 5 | 0.0 A | 0.2 A | 118.0 V | 0 W | 4 VA | On |
-------------------------------------------------------------------------------
Ostatus shows Outlet names
by Circuit number and outlet
number, True RMS Current,
Peak RMS Current, True RMS
Voltage, Average Power, Volt-
Amps and Outlet State.
IMPORTANT: This
option is available ONLY
if the Cascade feature has
been enabled.
Unit ID: MMP
7 56CE1
Total kW-h: 0
------------------------------------------
| Circuit | True RMS | Peak RMS |
| Breaker | Current | Current |
------------------------------------------
| CKT1 | 0.0 Amps | 0.0 Amps |
| CKT2 | 0.0 Amps | 0.0 Amps |
-------------------------------------------------------------------------------
| Circuit | True RMS | Peak RMS | True RMS | Average | Volt- |
| Group | Current | Current | Voltage | Power | Amps |
-------------------------------------------------------------------------------
| Circuit M1 | 0.0 Amps | 0.0 Amps | 199.4 Volts | 0 Watts | 4 VA |
| Circuit M2 | 0.0 Amps | 0.0 Amps | 201.9 Volts | 0 Watts | 4 VA |
| Circuit M3 | 0.0 Amps | 0.0 Amps | 201.3 Volts | 0 Watts | 4 VA |
| Circuit M4 | 0.0 Amps | 0.0 Amps | 200.6 Volts | 0 Watts | 4 VA |
| Circuit M5 | 0.0 Amps | 0.0 Amps | 200.0 Volts | 0 Watts | 4 VA |
| Circuit M6 | 0.0 Amps | 0.0 Amps | 200.9 Volts | 0 Watts | 4 VA |
-------------------------------------------------------------------------------
Int. Temp: 110.3 F Ext. 1: 69.9 F Ext. 2: 73.6 F : 38.8% RH
1)...MOD 1 Outlet 1 : On 2)...MOD 1 Outlet 2 : On
3)...MOD 1 Outlet 3 : On 4)...MOD 1 Outlet 4 : On
5)...MOD 2 Outlet 1 : On 6)...MOD 2 Outlet 2 : On
7)...MOD 2 Outlet 3 : On 8)...MOD 2 Outlet 4 : On
9)...MOD 3 Outlet 1 : On 10)...MOD 3 Outlet 2 : On
