RackMountHardware
Tool Less hardware installed on back of unit. If hardware is not needed, remove with
Phillips screwdriver.
Instructions to install M140C138 brackets to the Baytech vertical power strip.
In each unit locate the small bubble wrapped brackets containing two brackets and four screws. See
figure 1 and 2.
Figure1 Figure2
Line up the bracket holes to the holes on the unit. Figure 3.
Figure 3
Screw in two screws. Figures 4, 5, & 6 show the bracket mounted in three different positions.
Figure 4 Figure 5
Figure 6
