BBH SMX Series - Page 150

Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 150 of 260
Version: 25F
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
EXT-
ENC
X17
1 – U_ENC_3
1 – UE3+
Voltage supply encoder +24V DC X33
2 – GND_ENC_3
2 – UE3-
Voltage supply encoder 0V DC X33
3 – U_REF_3
3 – UR3
Reference voltage encoder X33
4 – NC
4 - NC
No function
X18
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 - NC
4 – NC
4 – NC
X27
1 – HTL_A_1
1 – H1A
Encoder 24V
2 - HTL_A_2
2 – H2A
Encoder A+
3 - HTL_A_3
3 – H3A
Encoder Ground
4 – NC
4 – NC
No function
X28
1 – HTL_B_1
1 – H1B
Encoder 24V
2 - HTL_B_2
2 – H2B
Encoder B+
3 - HTL_B_3
3 – H3B
Encoder Ground
4 - NC
4 – NC
No function
Terminal assignment
Unit
Terminal
Pin
Pin
SMXGen2 (/2)
Description
Note
EXT-
ENC
X19
1 – U_ENC_4
1 – UE4+
Voltage supply encoder +24V DC X34
2 – GND_ENC_4
2 – UE4-
Voltage supply encoder 0V DC X34
3 – U_REF_4
3 – UR4
Reference voltage encoder X34
4 – NC
4 - NC
No function
X20
1 – NC
1 – NC
No function
2 – NC
2 – NC
3 – NC
3 - NC
4 – NC
4 – NC
X29
1 – HTL_A_1
1 – H1A
Encoder 24V
2 - HTL_A_2
2 – H2A
Encoder A+
3 - HTL_A_3
3 – H3A
Encoder Ground
4 – NC
4 – NC
No function
X30
1 – HTL_B_1
1 – H1B
Encoder 24V
2 - HTL_B_2
2 – H2B
Encoder B+
3 - HTL_B_3
3 – H3B
Encoder Ground
4 - NC
4 – NC
No function
