BBH SMX Series User Manual

Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 22 of 260
Version: 25F
Technical characteristic data SMX100-1(/2, /4x, /5x, /x
(1)
)
Safety related characteristic data
Pl acc. to EN ISO 13849-1
PL e
PFH / architecture
8,0 FIT /Cat 4
SIL acc. to IEC 61508
SIL 3
Proof test interval
20 years = max. operating period
General data
Max. no. of expansion modules
8 *
Interface for expansion modules
T-bus connector, pluggable in top-hat rail
Number of safe digital inputs
14 (OSSD capable)
Number of safe digital outputs
pn-switching
2
Number of safe digital I/O
-
Number of relay outputs
2
Number of safe analogue inputs
-
Number of auxiliary outputs
2
Number of pulse outputs (clock outputs)
2
Type of connection
Plug-in terminals with spring or screw
connection
Axis monitoring
-
Encoder interfaces (D-Sub / screw terminal)
-
Encoder technology (See table encoder specifications)
-
SMXGen2 (/2)
Number of safe digital outputs
pn-switching **
2
pp-switching **
4
Electrical data
Supply voltage (tolerance)
24 VDC; 2A (-15%, +20%)
Fuse
X41.1, X61.1
min. 30 VDC; max. 3,15A
Max. power consumption (logic)
SMX100-1
2,4W
SMX100-1(/4x, 5x)
3W
Rated data digital inputs
24 VDC; 20mA, Typ1 acc. to EN 61131-2
Rated data digital outputs
pn-switching
24 VDC; 250mA
Auxiliary outputs
24 VDC; 250mA
Pulse outputs
(clock outputs)
24 VDC; 250mA
Rated data
relays
Normally open DC13
AC15
24 VDC; 2A
230 VAC; 2A
Rated data analogue inputs
-
SMXGen2 (/2)
Supply voltage (tolerance)
24 VDC; 2A (-15%, +20%)
Fuse
X41.1 / A1.1
min. 30 VDC; max. 3,15A
X41.2 / A1.2
min. 30 VDC; max. 10A
Max. power consumption (logic)
SMX100-1/2
2,8W
SMX100-1/2/x
5,2W
Rated data digital outputs
pn-switching
24 VDC; 2A ***
pp-switching
24 VDC; 2A ***
Electrical data (For UL only) SMXGen2 (/2)
Rated data digital outputs
pn-switching
Temperature rating
30°C
24 VDC; 2A (G.P.)
Temperature rating
50°C
24 VDC; 1,8A (G.P.)
pp-switching
Temperature rating
30°C
24 VDC; 2A (G.P.)
Temperature rating
50°C
24 VDC; 1,8A (G.P.)
Max. total current (pn or pp)
8A
Auxiliary outputs
24 VDC; 250mA (G.P.)
Rated data
relays
Normally open
24 VDC; 2A (Pilot Duty)
120 VAC; 2A (Pilot Duty)
Environmental data
Temperature
0°C … +50°C operation
