BBH SMX Series User Manual

Installation manual
HB-37420-810-01-25F-EN SMX100 Installation manual.docx Page 23 of 260
Version: 25F
-25C° … +70C° storage and transport
Class of protection
IP 20
Climatic category
3k3 acc. to DIN 60 721-3
Min-, Maximum relative humidity (no condensation)
5% - 85%
EMC
EN 61000-6-2, EN 61000-6-4, EN 61000-6-7,
EN 61800-3, EN 61326-3, EN 62061
Operating altitude
2000m
Overvoltage category
III
Degree of pollution
2
Mechanical data
Dimensions (HxTxB [mm])
SMX100-1 = 100x115x67,5
SMX100-1(/4x, /5x) = 100x115x90
SMXGen2 (/2)
SMX100-1/2 = 100x115x45
SMX100-1/2(/x
(1
) = 100x115x67,5
Weight (g)
SMX100-1 = 460
SMX100-1(/4x, /5x) = 560
SMXGen2 (/2)
SMX100-1/2 = 300
SMX100-1/2(/x
(1
) = 400
Mounting
To snap on top-hat rail
Number of T-bus connectors
SMX100-1
3
SMX100-1(/4x, /5x)
4
SMXGen2 (/2)
SMX100-1/2
2
SMX100-1/2(/x
(1
)
3
Min. terminal cross-section / AWG
0,2 mm² / 24
Max. terminal cross-section / AWG
2,5 mm² / 12
(*) Of which maximum of 6 axis modules
(**) pn/pp are configurable via SafePLC2
(***) Derating, see Chapter "Derating outputs"
(1)
Specification see: „Optional universal communication interface“
