Becker RT6201 Installation & Operation

AR6201 - RT6201 - RCU6201 - AR6203
DV 14307.03 Issue 1 09/2013 Page 1-11
Storage Temperature range ... -55°C to +85°C
Operating Temperature range .. -20°C to +55°C AR620X-(XXX) and RCU6201-(XXX)
-40°C to +55°C RT6201-(XXX)
short-time +70°C (all versions)
Operating Altitude ........... 35,000 ft
Vibration ................... Category S (Curve M) + Category U (Curve G)
1.7.3 Dimensions & Weight
AR6201-(XXX) AR6203-(XXX) RCU6201-(XXX) RT6201-(XXX)
Front
panel
61.2mm
x 61.2 mm
158.8mm
x 41.2 mm
61.2 mm
x 61.2 mm
61 mm
x 61 mm
Depth of
unit
187.8 mm
(front plate to
end of antenna
connector)
207 mm
(front plate
to end of
antenna
connector)
39.3 mm 188 mm
Mounting
(back panel)
standard
58 mm diameter
(2¼ inch)
Mounting Kit
MK6403-1
(back panel)
standard
58 mm diameter
(2¼ inch)
Mounting Kit
MK6201-(010)
or directly
on avionic
bay
Material AlMg AlMg/Plastic AlMg AlMg
Surface
treatment
Control-head coated with black matt paint
Weight 675g 850g 150g 600g
1.7.4 Receiver Data for AR620X and RT6201
Sensitivity ..................... ≤ -101 dBm for a (S+N)/N ratio of 6 dB
(nominal)
................................ ≤ -93 dBm for a (S+N)/N ratio of 6 dB
(qualified under environmental conditions)
Effective bandwidth ............. ≥ ± 2.78 kHz at the 6 dB points
(8.33 kHz channel spacing) ≤ ± 7.37 kHz at the 60 dB points
Effective bandwidth ............. ≥ ± 8 kHz at the 6 dB points
(25 kHz channel spacing) ≤ ± 22 kHz at the 60 dB points
Squelch ........................ level adjustable
AGC characteristic .............. ≤ 6 dB in range -93 dBm to 0 dBm
Distortion ...................... ≤ 15% at 30% 10dB below rated output power
≤ 15% at 70% and rated output power
Audio frequency response ........ ≤ 6 dB 350 Hz to 2500 Hz
(8.33 kHz channel spacing) ≥ 35 dB at 4000 Hz
Audio Noise ..................... ≤ 6 dB 300 Hz to 3400 Hz
≥ 18 dB at 4000 Hz
