Becker RT6201 Installation & Operation

AR6201 - RT6201 - RCU6201 - AR6203
Page 2-40 DV 14307.03 Issue 1 09/2013
2.9.2 Twin Seat Motor Glider
Installation Setup for Twin Seat Motor Glider
Sub-Menu
Function: / Selection
“SPKR VOLUME SOURCE BOTH
“CONFIGURATION” “SWAP MIKE IC” : Disabled
“IN/OUT CFG1”
(/MIKE_SW open):
“MICROPHONE 1” : STD_1 MIKE
“MICROPHONE 2” : NONE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Disabled
“IN/OUT CFG2”
(/MIKE_SW closed):
“MICROPHONE 1” : NONE
“MICROPHONE 2” : DYN_MIKE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Enabled
Remarks The external switch
(connected to pin J1-24 /MIKE_SW)
has the following functions:
• Open:
o Standard microphone is selected.
o Speaker is disabled.
o Intercom via VOX is possible.
• Closed:
o Dynamic microphone is selected.
o Speaker is enabled.
o No Intercom via VOX is possible.
o Permanent speaker sign is
visible on LCD screen.
