2.9.9 Installation Setup for Twin Seat with RT6201 Tandem Configuration
Installation Setup for Twin Seat with RT6201 Tandem Configuration
Sub-Menu
Function: / Selection
“SPKR VOLUME SOURCE BOTH
“CONFIGURATION” “SWAP MIKE IC” : Disabled
“IN/OUT CFG1”
(/MIKE_SW open):
“MICROPHONE 1” : STD1_MIKE
“MICROPHONE 2” : NONE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Disabled
If only headphone(s) are used, SPEAKER can
be disabled by selecting NONE.
If only speaker is used, HDPH 1 can be
disabled.
The standard microphone remains selected for
both configurations
“IN/OUT CFG2”
(/MIKE_SW closed):
“MICROPHONE 1” : STD1_MIKE
“MICROPHONE 2” : NONE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Enabled
Remarks The external switch
(connected to pin J1-24 /MIKE_SW)
has the following functions:
• Open:
o Headset 1 for pilot selected
o Headset 2 for copilot selected
o Speaker is disabled,
o Intercom via VOX is possible.
• Closed:
o Headset 1 selected (STD1)
o Headset 2 disconnected (STD2)
o Hand mike selected (STD3)
o Speaker is enabled
o No intercom via VOX is possible
o
if PTT is active then speaker is muted.
