J1 Connector (Serial Interfaces and Discrete I/O’s)
The J1 connector is a D_SUB female connector with 25 sockets and slide-in
fastener.
Pin No. Pin Name Direction Function
J1-1
CPIN
-
Reserved coding pin
J1-2
TX2+
OUT
Auxiliary control interface
J1-3 RX2+ IN Auxiliary Control Interface
J1-4 /SQL_EVAL OUT Squelch monitor output
ACTIVE state - closed contact to GND
J1-5 /PTT2 IN Press-To-Talk key input 2
ACTIVE state - closed contact to GND
J1-6 SHIELD_1 - Secondary control & service i
nterface
SHIELD
J1-7
TX1+
OUT
Secondary control & service interface
J1-8
RX1+
IN
Secondary control & service interface
J1-9
TX2-
OUT
Auxiliary control interface
J1-10
RX2-
IN
Auxiliary control interface
J1-11
SHIELD_2
-
Auxiliary control interface SHIELD
J1-12 /EXT_SO IN External ”Exchange” key
Falling edge will activate frequency
exchange
J1-13 /SRV_EN IN Service enable pin
ACTIVE state - closed contact to GND
J1-14
TX1-
OUT
Secondary control & service interface
J1-15
RX1-
IN
Secondary control & service interface
J1-16
NC
not connected
J1-17 /SQL_SW IN “Squelch Force-OFF” input
ACTIVE state - closed contact to GND
J1-18
NC
not connected
J1-19
NC
not connected
J1-20 /ISOL IN “ISOL” input
ACTIVE state - closed contact to GND
J1-21
D_GND
-
Discrete lines ground
J1-22
D_GND
-
Discrete lines ground
J1-23
D_GND
-
Discrete lines ground
J1-24
/MIKE_SW
IN
Configuration selector CFG1 and CFG2
J1-25 /EXT_ON IN External Power ON input
ACTIVE state - closed contact to GND
