AR6201 - RT6201 - RCU6201 - AR6203
Page 2-62 DV 14307.03 Issue 1 09/2013
Power the GPS and make sure that not less than 5 satellites are tracked.
Check the interference between the VHF-COM and the GPS receiver (when
activated in NAV mode). Select the following channels/frequencies on the
AR620X and on each frequency stay in TX and RX mode for at least 30 seconds.
Verify that GPS integrity Flag is always out of view.
Channel Frequency
(MHz)
121.140 121.1416
121.150 121.1500
121.155 121.1500
121.160 121.1583
121.165 121.1666
121.175 121.1750
121.180 121.1750
121.185 121.1833
121.190 121.1916
121.200 121.2000
121.205 121.2000
121.210 121.2083
131.240 131.2416
131.250 131.2500
131.255 131.2500
131.260 131.2583
131.265 131.2666
131.275 131.2750
131.280 131.2750
131.285 131.2833
131.290 131.2916
131.300 131.3000
131.305 131.3000
131.310 131.3083
