3.4.1 NOxBOX
i
System Features
1. Touch Screen Display
2. ModeSelectionValve
3. ManualOverrideFlow
 ControlValve
4. NOxFlow Sensor
Connector
5. NOxFlow Dose
Connector
6. Patient Sample Inlet
7. Water Trap Bottle
1
2
3
8. Handle
9. Quick Release Button
10. Power Inlet Socket
11. Charging Indicator LED
12. Zero Inlet
13. USB Port
14. Power Button
15. NOxBOXigasinlets:4
bar max.
16. Gas Line Purge Needle
4
5
6
7
8
9
10
11
12
13
14
15
16
