Bedfont NoxBox - Manual Override Flow Selector: Approximate no Flow Values

66
The system screen will display a
warning message that the system is
deliveringthroughtheManualOverride
mode.
Press the cross to dismiss this
message.
The“NODose”areaofthemainscreen
shows a constant reminder that the
systemisonManualOverride.
Toreverttointelligentdelivery,position
themodeselectionvalvetovertical.
6.12.4 Manual Override Flow Selector: Approximate NO ow values
50 50 cc/min
100 100 cc/min
200 200 cc/min
300 300 cc/min
400 400 cc/min
500 500 cc/min
Noteallvaluesshownareapproximateto+/-
15%. Refer to look-up tables for indication of
doseperventilatorowrate.
Monitoring of patient dose must be
implemented when using Manual
OverrideowdeliveryofNO.
6.13 Shutdown
Whenreadytoshutdownthesystem,pressand
hold the power button on the monitor for two
seconds until the System Shutdown screen is
displayed.
Conrmshutdownonscreen.Followon-screen
instructions.
600 600 cc/min
