5.4 Vent circuit Example 2
1. Sensormedics3100aVentilator
2. Ventilatorbiasowoutlet
3. NOxFlow(use22For15Mtoventtubeadaptors)
4. One-wayvalve
5. Humidier
6. Sampling point
7. NOxBOX
i
sample line
8. NOxBOX
i
5.5 Manual bagging & Manual override
5.5.1 Setup
When using the NOxBOX
I
withmanualbaggingorNeopuffcircuit,theManualOverridemodemust
beselected(seesection6.12).Adaptorsforthebelowcircuitscanbeobtainedfrom
BedfontScientictoensurecompatibility.
TheNOxFlowdeliverylineshouldbedisconnectedfromtheNOxBOX
i
andamanualbagspecic
line is connected to the NOxBOX
i
NOoutletport(femaleleurconnection)duringmanualbagging.
Inthecaseofhyper-inatingandself-inatingcircuits,anO
2
supply is typically required and can be
connectedtoavariableowO
2
sourcesuchasawalloutletwithadjustableowmeter,ora
cylinderwithadjustableow.
CorrectNOdosecanbecalculatedandadjustedeitherbythechangingofthemanualcontrol
valvepositionoradjustmenttheowrateoftheO
2
source(seesections6.12.1&6.12.2).
Monitoring of the dose should be carried out by connection of the sample line to the manual
bagging circuit.
