Bedfont NoxBox - System Test Setup

30
13. Onceallconnectionshavebeenremade,retestthepressurehold.Ifthelinefailsagain
 thesystemwillpromptusertoconnectthesecondlineinstead.Calltheserviceengineer
 tomakesurethatanyproblemwiththerstsupplylinecanberesolved,orthesystem
replaced as soon as practical.
Repeatthestepsaboveforthe
second supply line
If both lines fail after following
theaboveprocedure,thismay
indicate an internal leak in the
system. The system must be
inspected and repaired by a
qualiedserviceengineerbefore
being used.
4.5 System Test Setup
1. Unwrap a new NOxFlow sensor and
unroll the lines.
2. Identify the single dose-line luer
connector and attach to the monitor
dose luer port as shown. Twist
connector to lock.
14.
