QTERM-G56 Terminal Supported Interfaces
Qlarity-Based Terminal Hardware 57
4.2.2.8 Additional Serial Interface with E-Stop Option and Integral Cable (without Ethernet
option)
The following table shows the pinout for the EIA-232 serial interface with integral cable and
E-stop option.
4.2.2.9 Network Interface with E-Stop Option and Integral Cable (with Ethernet option)
The following table shows the pinout for the 10/100Base-T network interface with integral
cable and E-stop option.
4.2.2.10Serial Interface with E-stop Option and Integral Cable (with Ethernet option)
The following table shows the pinout for each type of serial or network interface.
N
OTE
☞
Due to pin constraints, the EIA-422 and EIA-485 multiprotocol serial port interfaces are not
available with the E-stop/integral cable/Ethernet options, and the EIA-232 interface does not
have RTS/CTS flow control. The terminal should be set in software or Power On Setup to
EIA-232 only with no hardware handshaking
4.2.2.11E-stop Switch Interface with Integral Cable
The following table shows the integral cable pinout for the two-pole normally closed E-stop
switch. The conductors for each pole (Pole 1 and Pole 2) of the switch are shorted until the
switch is activated. After activation, each pole is an open circuit until the switch is reset.
Pin EIA-232
7Tx
6Rx
DB15f Pin Ethernet
7Tx+
14 Tx-
6Rx+
13 Rx-
DB15f Pin EIA-232
4Tx
10 Rx
DB15f Pin E-stop Switch
5Pole 1
8Pole 1
11 Pole 2
12 Pole 2
