QTERM-Z60 Terminal Supported Interfaces
Qlarity-Based Terminal Hardware 75
6.2 Supported Interfaces
6.2.1 Serial Ports
The QTERM-Z60/H comes standard with one user-selectable serial port. The serial port inter-
face can be selected via dip switches (EIA-232, EIA-422 or EIA-485). The QTERM-Z60/L is
equipped with one EIA-232 serial port.
N
OTE
☞
The serial port is wired as Data Communications Equipment (DCE)
The interface is selected using DIP switches. The following table shows the dip switch set-
tings.
Vibration 5 to 5000 Hz, 4 g RMS
Shock 20 g, 3 ms, any axis
POWER
8 to 32 VDC (See section 6.4.3 for current consumption)
SOFTWARE
Programming language Qlarity (object-based)
Design environment Qlarity Foundry (Windows)
Command line compiler Qlarify (Win32 or Linux)
CERTIFICATION
FCC Part 15, Class A
CE Certification
ENVIRONMENTAL
Dip Switch Settings
12345678
EIA-232 off off off off off on off off
EIA-422 off off off off on off off off
EIA-485onononononoffoffoff
