Chapter 2 System Overview
Example of Usable Printer or Equivalent Printer Specifications
Brand: Epson TM-U200D
511
Model: M119D
Dipswitch settings are as follows: Dipswitch #1: turn ON #1-3 all others must be OFF
Dipswitch #2: make sure all are OFF
Cable to printer must be a (modem cable) 9-pin to 25-pin, this is where pin #2 is inverted with
pin #3 and pin #3 is inverted with pin #2 as shown below:
9-Pin Connector End 2 2 25-Pin Connector End
2 2
If your cable does not work try a null modem 9-pin adapter.
#1 Dipswitch 1 2 3 4 5 6 7 8
ON
X
OFF
X X X X X X X
#2 Dipswitch 1 2 3 4 5 6 7 8
ON
OFF
X X X X X X X X
Printer Setup RS-232
Page length 60
Hand shake XON / XOFF
New line character CR / CF
Baud rate 9600
Parity None
Data bits 8
Stop bits 1
