INTEGRA® / E-1063
1MANUL102 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 5-7
Setup
Setup / Functions
Functions
Functions are OUTPUTS that turn ON/OFF at positions determined by that Function’s parameters. Some functions have one
output others have more. Functions are all programmed very similarly with a few different components. (Functions should be
setup and named before packages or Options are setup).
Below is a summary of the User Defined settings that can be programmed in Functions.
• Name: Touch the “NAME” for the alpha/numeric pop-up to display for changing the name. Not all Functions are user
namable.
• On Position: This dictates the tunnel location that a function will turn ON (from the “Entrance Photo-Eye” to the
desired “ON” point). Minimum setting is 8 inches. Set to zero for off-line Functions that come on before the vehicle
enters the Photo-Eye.
• On For - - - > Pressing the selection toggles between the following two options
• Set Distance: When in this mode, the function will be ON for a specified distance for each vehicle.
• Car Length: When in this mode, the Function will be ON for the car length plus the length Adjust setting. The
Adjust setting can have a value of + or -. Typically “length adjust” is slightly longer than the equipment length.
• Set Distance: When using the Set Distance feature, this displays the number of inches that a given function will be
ON. All have a maximum distance of 240 inches except “Named 30” which has a maximum distance of 999 inches.
• Car Length Adjust: This is to adjust the distance that the function will be ON. This can be +/- of the measured car
length.
• Lookback Distance: This will keep the Function active if next vehicle is within Lookback distance. This setting
does NOT work when the Function is in “Set Distance”. Set Lookback distance below “8” to disable.
