Chapter 6 Techniques in Wash Setup
Additional Information
Auto clearing of QUEUE. This function will only be active if EZ-Load Photo-Eye is wired into the
system. If a Wash is in STANDBY or in Queue for 5 minutes without either the “EZ-Load Photo-
Eye” or the “Bay Enter Photo-Eye” being broken; or the E-Stop being pressed, the system will
clear the queue and standby automatically.
Offline Functions: These are functions that turn on before the vehicle enters the Photo-Eye. To program a function
to operate offline, change value “On Position” to Zero. See SETUP/FUNCTIONS for more information.
If on AirBlade™ Express 180 is ordered: A 60HP and a 40HP VFD Panel will be shipped. The 40HP Dryer will
need Station Numbers changed to range between 15 and 20 because the 60HP utilizes 9 to 15. See supplied prints
for parameter lists.
If wash is to be paused by personnel at the exit of the tunnel instead of using Anti-Collision Photo-Eyes:
Connect a “maintained, normally closed” button to the Anti-Collision inputs. Using the E-Stop to pause the wash will
require the wash condition to be accepted at the E-1063 to resume washing.
