Chapter 6 Techniques in Wash Setup
Recommended Initial Settings
Note:
Conveyor Pulse Distance should be set to 8.26 on Belanger DXD systems. All of these
settings assume 48” Dollie spacing.
Note: POS shown is for Unitec™ product. Hamilton™ products typically get set to “Wash
Done”.
Unattended, 1 Step, Rear Tire Push
E-1063 Loading Screen E-1063 P.O.S. Screen
Dollie Up Count
Direct Select Inputs
Front Auto Dollie Off
03F = Wash In Use
*
Rear Auto Dollie On
*
Screen / Alt. Accept
01 = Auto Front Dollie
*
Alt. Accept Is Timed
02 = Auto Back Dollie
3 Seconds Timed Load
02 = Dollie Call Dollies
100 = Neutral Distance
EZ – Load Photo Input Is
Not Used In Tire Eval
Repeat Size Dollie Enabled
*
Disable – Front Pull No Treadle
*
*
Enable – Rear Push No Treadle
= Selection that MUST be set to match for
this type of vehicle loading
*
Auto Size Dollie Enabled
288 = Max Car Length
Unattended, Front Tire Pull with Treadle
E-1063 Loading Screen E-1063 P.O.S. Screen
Dollie Up Count
Direct Select Inputs
*
Front Auto Dollie On
03F = Wash In Use
*
Rear Auto Dollie On
*
Screen / Alt. Accept
01 = Auto Front Dollie
*
Alt Accept Is Input
02 = Auto Back Dollie
01 = Dollie Call Dollies
EZ – Load Photo Input Is
Used In Tire Eval
50 = Minimum Inches Between Tires
Use Minimum Distance Between Tires
100 = Neutral Distance
*
288 = Max Car Length
= Selection that MUST be set to match for
this type of vehicle loading
Repeat Size Dollie Enabled
*
Disable – Front Pull No Treadle
*
Disable – Rear Push No Treadle
*
Auto Size Dollie Disabled
