INTEGRA® / E-1063
5-8 Belanger, Inc. * 1001 Doheny Ct. * Northville, MI 48167 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL102
Chapter 5 Operator Interface/Wash Setup Screens
Setup
Setup / Functions
Function Setup Screens (typical)
• Power Up Delay: This feature is not available on all Functions This is how long the Function will wait to turn back on after
recovering from a Power Down or an E-Stop condition. Time will be 2.5 seconds longer due to the time required to sound
the horn. Typically used for turning ON high current loads.
• Stagger Delay (Dryers ONLY): This Function appears only when programming Dryer Functions. It is the time between
powering up the different outputs of the Dryer Function.
• Top Wheel Retract Function: Leg mounted Photo Eye tree can be purchased for the Top Wheel to automatically detect
pick-up truck beds. The NAMED 6 Output (020) will need to be wired to the Top Wheel Retract pneumatic valve. This
function can be “Feather-Touch” or “Retract” depending on air regulator setting. The Photo Eye Tree should be mounted
with the Photo Eyes on the entrance side of the Top Wheel legs with upper Photo Eye sensor 60” off of the floor and the
lower Photo Eye sensor 40” off of the floor.
• Enable Distance: Typically set to 20”. Once upper Photo Eye beam is broken it will need to be broken again after
this distance in order for the system to look for pick-up truck beds.
• Active Distance: Typically set to 36”. If the system is looking for a pick-up truck bed and the upper Photo Eye beam
is made for the set distance while the lower Photo Eye beam is broken, the “Retract” Output (NAMED 6) will turn
ON/OFF for Anti-Collision. Toggle between ON/OFF during Anti-Collision condition.
• Top (ON/OFF) for Retract: This determines the state of the output when the Top Wheel retract function is retracting the
Top Wheel.
Note: If there are two Top Wheels installed that require automatic retracting, the NAMED 7
must be utilized for the second Top Wheel. The second Top Wheel on NAMED 7 must
be positioned further down the bay than the Top Wheel on NAMED 6. The Top Wheel
in NAMED 7 will retract at a position determined by sensors on the NAMED 6 Top
Wheel.
• ON/OFF for Anti-Collision: Toggles between ON or OFF during Anti-Collision condition.
• Package Light Value: This should be set to zero in order to disable. This feature is available on NAMED 31 – 46. When
a Package Value is entered here, the function will turn ON when the next vehicle is receiving that Package and no vehicle
is in the Photo-Eyes.
• Operate Normal Function / Operate vehicle Tires: When set to “Operate vehicle Tires”, the function will output twice
per vehicle. Once for the front tires and once for the back tires. See the MISC screen for Tire Sensor Setup. This feature
works for NAMED 19, 20, 45 and 46.
• Front Start: This is where the Output will turn ON for the front tires. This position is relative to where the sensor
detected the front tires. Its typical value is negative.
• Front End: This is where the Output will turn OFF for the front tires. This position is relative to where the sensor
detected the front tires. Its typical value is positive.
• Back Start: This is where the Output will turn ON for the back tires. This position is relative to where the sensor
detected the back tires. Its typical value is negative.
• Back End: This is where the Output will turn OFF for the back tires. This position is relative to where the sensor
detected the back tires. Its typical value is positive.
