SpinLite® Full Side Washer
1MANUL961 Belanger, Inc. * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 41
Installation
Install Hub Assemblies, LED Lights with Electrical Connections & ShineMitts™
Load ShineMitts™ on Hub Assemblies
20) Lastly, retrieve the 32 pieces of the 25” (111369) cleaning material there should be 16 pieces
assembled for the driver side and 16 for the passenger side SpinLite® FSW assemblies.
21) If there is not an equal number of the 25” ShineMitt™ (111369) assembled properly for the driver
side and passenger side SpinLite® FSWs follow the rework process explained in Steps 7-10 in
this section.
22) Install a total of two (2) rows of the 25” ShineMitt™ material on each Hub in the same orientation
as the previous ShineMitts™. Be sure to slide the ShineMitts™ down until they rest on top of the
previous row. Refer to the image below.
Hub: 111673
Diameter: 7”
Height: 66.25 “
111369 (Qty. 8 per Hub)
25” - 45 DEG Short Lead
111369 (Qty. 8 per Hub)
25” - 45 DEG Short Lead
111060 (Qty. 8 per Hub)
19” - 45 DEG Short Lead
111060 (Qty. 8 per Hub)
19” - 45 DEG Short Lead
111060 (Qty. 8 per Hub)
19” - 45 DEG Short Lead
111060 (Qty. 8 per Hub)
19” - 45 DEG Short Lead
111060 (Qty. 8 per Hub)
19” - 45 DEG Short Lead
111053 (Qty. 8 per Hub)
22” - 45 DEG Short Lead
111053 (Qty. 8 per Hub)
22” - 45 DEG Short Lead
111053 (Qty. 8 per Hub)
22” - 45 DEG Short Lead
111053 (Qty. 8 per Hub)
22” - 45 DEG Short Lead
Step 22:
Load the top two (2) rows of each Hub with the
25” ShineMitt™ cleaning material; 8 pieces per
row. Make sure to slide the ShineMitts™ down
until they rest on top of the previous row.
