Technical data IRDH575
104
IRDH575_D00089_05_M_XXEN/01.2020
Maximum system leakage capacitances for the insulation fault lo-
cation system EDS470
Curve 2a:
Maximum allowable system leakage capacitance in relation to the system vol-
tage to be monitored. Up to this limiting value of the system leakage capaci-
tance, the EDS system has the sensitivity illustrated in curve 1a.
Curve 2b:
Maximum allowable system leakage capacitance in relation to the system vol-
tage to be monitored. Up to this limiting value of the system leakage capaci-
tance, the EDS470 system has the sensitivity shown in curve 1b.
0
10
20
30
40
50
60
70
80
90
100
24 48 110 230
U
n
(V)
C
e
(µF)
AC
3AC
DC
0
0,5
1
1,5
2
2,5
3
3,5
4
4,5
5
230 400 500 690 1000 (V)
C
e
(µF)
AC
3AC
DC
U
n
