PL-6000DC/DCX Two-Post Parking Lift 25 P/N 5900273 — Rev. A6 —July 2024
Drawing not to scale.
Slide the Lift Carriage up on both Posts until the Safety lock engages at about 24” / 600 mm.
⚠ WARNING The Lift Carriages are heavy, use assistance to slide them along the post.
Anchoring the Powerside Post
The Powerside Post must be anchored to prevent movement.
⚠ WARNING You must always wear OSHA-approved (publication 3151) appropriate protective
equipment during installation: leather gloves, steel-toed work boots, eye protection,
back belts, and hearing protection are mandatory.
⚠ WARNING The Lift Posts are heavy and the weight is not evenly distributed. Use proper tools,
Forklift or Shop Crane, and assistants to move the posts into position.
Stand-up the Powerside Post and move it to the location marked by the chalk lines created
earlier.
