PL-6000DC/DCX Two-Post Parking Lift 27 P/N 5900273 — Rev. A6 —July 2024
Drawing not to scale.
Do not stand up the Offside Post yet.
Attach the Side Beams, Back Plate and Connection Rods
This section addresses attaching the Side Beams, Connection Rods, and Back Plate. These
components are heavy.
⚠ WARNING You must always wear OSHA-approved (publication 3151) appropriate protective
equipment during installation: leather gloves, steel-toed work boots, eye protection,
back belts, and hearing protection are mandatory.
